NEC NEAX2000 IVS2 Installation Manual page 493

CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
PN-M03 (M03)
Lamp Indications
LAMP
COLOR
NAME
OPE Green
RS Green
SD Green
RD Green
CD Green
ER Green
DR Green
CS Green
SELX21 Green
SELCN0 Green
Page 464
ON: This card is normally connected to the PN-2DPCB.
OFF: This card is abnormally connected to the PN-2DPCB.
ON: RTS signal is ON.
OFF: RTS signal is OFF.
ON: TXD signal is "0" (Space condition).
OFF: TXD signal is "1" (Mark condition).
ON: RXD signal is "0" (Space condition).
OFF: RXD signal is "1" (Mark condition).
ON: DCD signal is ON.
OFF: DCD signal is OFF.
ON: DTR signal is ON.
OFF: DTR signal is OFF.
ON: DSR signal is ON.
OFF: DSR signal is OFF.
ON: CTS signal is ON.
OFF: CTS signal is OFF.
ON: Connecting to the PN-2DPCB is available.
OFF: Connecting to the PN-2DPCB is not available.
Not used
