CHAPTER 1 GENERAL INFORMATION
Equipment Name and Function
Table 1-5 Line/Trunk Card Name and Function (Continued)
EQUIPMENT FUNCTIONAL
NAME
PN-4LCL LC
[For China]
PN-4LCV LC
[For Brazil]
PN-4LCW LC
[For Brazil]
PN-8LCAA LC
PN-8LCAB LC
[For China]
PN-2LDTA LDT
[For
Australia/
Others]
PN-4LDTA LDT
[For
Australia/
Others]
Page 26
NAME
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Message Waiting Lamp control, Line Test functions
for each circuit, and reverse function for only No. 3 circuit.
Equipped with +80V DC-DC on-board power supply.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Line Test function.
4-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Message Waiting Lamp control, Line Test functions
for each circuit, and reverse function for only No. 3 circuit.
Equipped with +80V DC-DC on-board power supply.
8-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 600 Ω (including telephone set)
Provides Message Waiting Lamp control, momentary open,
Line Test functions for each circuit.
8-line Analog Line Circuit Card for Single Line Telephones
Loop resistance : Maximum 1200 Ω (including telephone set)
Provides Message Waiting Lamp control, momentary open,
Line Test functions for each circuit.
2-line Loop Dial Trunk Card
Line resistance : Maximum 2500 Ω (including internal
resistance of the distant office equipment)
Equipped with –48V DC-DC on-board power supply.
4-line Loop Dial Trunk Card
Line resistance : Maximum 3000 Ω (including internal
resistance of the distant office equipment)
PZ-PW122 is required.
FUNCTION
2
