CHAPTER 1 GENERAL INFORMATION
Mounting Conditions of Circuit Card
(5) Mounting Conditions of Each Card
CARD NAME
PN-PW00
PN-CC01
PN-BRTA
PN-2BRTC
PN-2BRTK
PN-24CCTA
PN-30CCTA
PN-24DTA-C
PN-30DTC-A/PN-30DTC-C
PN-24PRTA
PN-30PRTA
PZ-M542
PZ-M557
Page 40
MOUNTING CONDITIONS
No circuit card can be mounted in the adjoining left side slot
because one card occupies two physical slots width.
Mount the PN-CC01 card in the slot that adjoins the PN-AP01
card. Connect both cards using cable (48-TW-0.3 CONN CA).
Mount at least one card in PIM 0 to receive source clock signals.
Mount the PZ-M542/PZ-M557 card into any LTC connector of
PIM BWB.
A maximum of two cards can be mounted per PIM as follows:
LTC0 and LTC2
LTC0 and LTC3
LTC1 and LTC3
