CHAPTER 2 INSTALLATION
SN716 DESKCON (DLC)
STEP 4: Plug the headset into the modular jack (H/S 0 or H/S 1) located at the bottom of the
console, if required.
Figure 2-71 Headset Installation for SN716 DESKCON
Page 170
ATTENTION
Contents
Static Sensitive
Handling
Precautions Required
HAND
H/S 0
H/S 1
2
NEAX2000 IVS
Installation Procedure Manual
ND-70928 (E), Issue 3.0
