CHAPTER 2 INSTALLATION
Installation of Main Equipment
A
INSTALLATION
OF PIM
INSTALLATION OF
MULTIPLE-MODULE
INSTALLATION OF
TOP COVER
INSTALLATION OF
MOUNTING BRACKET
CHECKING
END
Page 64
• For Fixed Equipment
(1) Fix the BASE PLATE to the floor with anchor bolts.
(2) Fix the BASE to the BASE PLATE with screws. See
(3) Fix the PIM onto the BASE with screws. See
• For Stationary Equipment
(1) Fix the BASE TRAY to the floor with anchor bolts.
(2) Fix the PIM onto the BASE with screws. See
(3) Place the Module and the BASE on the BASE TRAY. See
2-15.
• Connect PIMs with screws. See
• Install the I/F BRACKET to the top-stack PIMs if the equipment is
stacked with five or more PIMs. See
• Install the TOP COVER to the top-stack PIM. See
COVER".
• Install the MOUNTING BRACKET to the top-stack PIM if the equipment
is stacked with four or more PIMs. See
BRACKET".
• Carefully review every step above to ensure that all necessary screws
are properly placed and tightened.
Figure
Figure
Figure 2-18.
"Installation of I/F
"Installation of TOP
"Installation of MOUNTING
2
NEAX2000 IVS Installation Procedure Manual
Figure 2-13.
2-14.
2-14.
Figure
BRACKET".
