CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
PN-DAID (DAI)
SWITCH NAME
SW2 (DIP SW)
ON
1 2 3 4 5 6 7 8
Page 324
SWITCH SETTING
NUMBER POSITION
ON
4
OFF
ON
5
OFF
ON
6
OFF
ON
7
OFF
ON
OFF
8
FUNCTION
Setting of control signal time slot
SWITCH NUMBER
4 5 6 7
OFF ON ON ON
ON OFF ON ON
OFF OFF ON ON
ON ON OFF ON
OFF ON OFF ON
ON OFF OFF ON
OFF OFF OFF ON
ON ON ON OFF
OFF ON ON OFF
ON OFF ON OFF
OFF OFF ON OFF
ON ON OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
OFF OFF OFF OFF
ON ON ON ON
OFF ON ON ON
ON OFF ON ON
OFF OFF ON ON
ON ON OFF ON
OFF ON OFF ON
ON OFF OFF ON
OFF OFF OFF ON
ON ON ON OFF
OFF ON ON OFF
ON OFF ON OFF
OFF OFF ON OFF
OFF ON OFF OFF
ON OFF OFF OFF
OFF OFF OFF OFF
NOTE 4: Time Slots 0 and 28 (TS0/
28) cannot be used for
control signal.
NOTE 5: This setting
identical with the opposite
DAIE card.
NEAX2000 IVS
CHECK
TIME SLOT
NUMBER
8
ON TS 4
ON TS 5
ON TS 6
ON TS 7
ON TS 8
ON TS 9
ON TS 10
ON TS 11
ON TS 12
ON TS 13
ON TS 14
ON TS 15
ON TS 16
ON TS 17
ON TS 18
OFF TS 19
OFF TS 20
OFF TS 21
OFF TS 22
OFF TS 23
OFF TS 24
OFF TS 25
OFF TS 26
OFF TS 27
OFF TS 28
OFF TS 29
OFF TS 30
OFF TS 29
OFF TS 30
OFF TS 31
must be
2
