(4) Mounting Application Processor Cards in PIM 1-7
Use Slots AP00 to AP11 to mount application processor cards in PIM 1 through 7.
Figure 1-13 Application Processor Card Mounting Slots (PIM 1-7)
AC/DC
PIM
PWR
1 - 7
DC/DC
PWR
*1 Application processor cards can be mounted in AP00 to AP11 slots.
2
NEAX2000 IVS
Installation Procedure Manual
ND-70928 (E), Issue 3.0
LTC1
LTC0
BWB
FRONT
CHAPTER 1 GENERAL INFORMATION
Mounting Conditions of Circuit Card
*
1
LTC3
LTC2
Page 39
