CHAPTER 2 INSTALLATION

BUS Cable Connection

BUS Cable Connection
When the system is a multiple-PIM configuration, connect all BUS Connectors to each other
using BUS cables, as shown below.
Be sure to secure the BUS cables using tie wraps to avoid obstructing a PFT card.
Connection of BUS Cables
P
W
PIM 3
R
P
W
PIM 2
R
P
W
PIM 1
R
P
W
PIM 0
R
Page 92

Figure 2-27 BUS Cable

700 mm (27.6 inch)
48-TW-0.7 CONN CA
P
W
R
P
W
R
P
W
R
P
W
R
BUS CABLE
PIM 7
TIE WRAP
PIM 6 FRONT
PIM 5
PIM 4
48-TW-0.7 CONN CA
2
NEAX2000 IVS
PZ-8PFTB
CARD
Installation Procedure Manual
ND-70928 (E), Issue 3.0
