CHAPTER 3 LAMP INDICATIONS AND SWITCH SETTINGS
PN-PW00 (EXTPWR)
PN-PW00 (EXTPWR)
Locations of Lamps, Switches, and Connectors
Lamp Indications
LAMP
COLOR
NAME
RUN
Green
Page 246
CONN
Remains lit while –48V power is being supplied
08
07
06
05
RUN
04
MB
03
02
01
TO DESKCON
FUNCTION
NEAX2000 IVS
-48V
-48V
E
E
-48V
-48V
E
E
2
Installation Procedure Manual
ND-70928 (E), Issue 3.0
