End point
correct improper linkage settings.
Linkage menu to call the setup
screen shown below.
Linkage menu
1. Tap the travel button of the channel you
want to set. Value input buttons appear on
the screen.
2. Use these buttons to adjust the rate.
3. Repeat the procedure above for each rate.
Sets the travel, limit point.
Travel rate
Left / Top
Indicates the current
direction of the stick, etc.
1. Tap the limit button of the channel you want
to set.
2. Use the value input buttons to adjust the limit
point.
3. Repeat this procedure for each limit point.
76
30 〜 30 〜
140% 140%
Limit point
Next page
Ch7-16
Tap the values you
wish to adjust and
value input buttons
will appear on-screen.
Right / Bottom
