FUTABA T16IZ SUPER Full Manual page 43

1. Place the transmitter and the receiver close
to each other within half (0.5m) meter.
Less than 0.5 m
2. Turn on the transmitter.
3. Select [System type] at the Linkage menu
and access the setup screen shown below
by tapping the screen.
4. When you use two receivers on one model,
you must change from [Single] to [Dual].
*Only two receivers can be used. In
"Dual", two setting items come out. Input,
respectively.
ID of a primary
receiver displays.
In Dual, a primary receiver (Rx1) is
linked first. Next, a secondary (Rx2)
receiver is linked.
5. Battery fail-safe voltage can be changed
from the initial value of 3.8V here.
* Only in FASSTest/T-FHSS Mode.
LINK
ID of a secondary
receiver displays.
43
6.[Link] is tapped. The transmitter will emit a
chime as it starts the linking process.
7. When the transmitter starts to chime, power
on the receiver. The receiver should link to
the transmitter within about 1 second.
In "Link" Mode
8. If linking fails, an error message is displayed.
Bring the transmitter closer to the receiver
and repeat the procedure above from Step 2.
Receiver ON
