FUTABA T16IZ SUPER Full Manual page 145

Airbrake → ELE
raises the elevators to correct for dropping of the
nose during airbrake operation.
elevator servos can be adjusted.
setting a switch. (Always ON at [--] setting)
menu and call the setup screen shown
below.
● Mixing curve setting
(For a description of the
setting method, see the
description at the back
of this manual.)
Activate the function by
tapping the [INH].
Condition group/single
mode selection (Gr. /Sngl)
The ON/OFF switch of
mixing is chosen.
(ON is displayed.)
the switch and tap the screen to call the
selection screen, and then select the switch
and set its ON direction. (Always ON at "--"
setting)
(For a description of the switch selection
method, see the description at the back of
this manual.
[Corresponding model type]:
Airplane/glider, general
ELEVATOR
*The display screen is an example. The actual
screen depends on the model type.
Currently selected condition name
"--" item and tap the screen to call the
selection screen, and then select the VR. The
adjustment rate can be set. The VR operation
mode can also be set.
method, see the description at the back of
this manual.)
(For a description of the curve setting
method, see the description at the back of
this manual.)
145
AIR BRAKE
V-TAIL
ELEVATOR
ELEVATOR 2
Up/Down overall
adjustment at Rate A
and Rate B
Adjustment of
elevator servo
Fine tuning
setting
AILVATOR
ELEVATOR 2
