FUTABA T16IZ SUPER Full Manual page 153

Snap roll
a snap roll is performed.
right/down, left/up, left/down)
the Snap Roll function is turned ON/OFF by master
switch in the state in which the direction switch
was switched to the direction in which you want
to snap roll. When [Single] mode is selected, snap
roll in each direction can be executed by means
of independent switches.
the switch can be set so that snap roll is not
executed when, for instance, the landing
gear is lowered, even if the switch is turned on
accidentally. The snap roll switch is activated only
when the safety switch is ON.
direction. (In side/out side)
and call the setup screen shown
below.
Master or Single is
chosen
Snap roll
directions
[Corresponding model type]: Airplane, general
Master mode : Direction
switches
Single mode : Snap roll
switches
(Example) Setting example for F3A
executing snap roll)
Right/Up: [SW-D] OFF-OFF-ON
Right/Down: [SW-D] ON-OFF-OFF
Left/Up: [SW-A] OFF-OFF-ON
Left/Down: [SW-A] ON-OFF-OFF
The operation speed of each control
surface when the snap switch is ON can
be changed and snap roll executed by
stick while there is switch operation can be
performed.
The ON/OFF switch
of snap roll is chosen.
Aileron, elevator and
Rudder rate adjustment
153
The safety switch is
chosen.
To next page
Condition group/
single mode
selection (Gr. /Sngl)
In speed
Out speed
（First） 0 〜 27 （ Slowly） （First） 0 〜 27 （ Slowly）
