FUTABA T16IZ SUPER Full Manual page 235

Curve setting operation Spline curve
A smoother curve is made.
Setting method is same at spline and point.
Point
Spline curve
The kind of mixing curve
Point curve (Point) adjustment
(Point)
Initial point number: 9 points (17
points curve), 7 points (11 points
curve)
Spline
[Rate adjustment of each point]
*The mark
the currently selected point.
2. Tap to the [Rate]
*[Separ.] mode: Normal setting
*[Comb.] mode: Creates a left and right
235
Initial point number: 9 points (17 points
curve), 7 points (11 points curve)
1. Tap to the
and select the point whose
rate you want to set.
i t e m . A n d s e t
t h e r a t e u s i n g
Repeat steps 1 through 2 and adjust the
curve.
symmetrical curve.
item
