Telemetry : Altitude [Variometer]
variometer information from an optional altitude
sensor or GPS sensor.
to call the setup screen shown below.
Linkage menu
Max. and min. values
s i n c e t h e p o w e r
was turned ON will
display.
↑ An upward arrow
indicates the alarm
will sound when the
variometer reaches
above your set value.
↓ A downward arrow
indicates the alarm
will sound when the
variometer reaches
below your set value.
Alarm is chosen from
Buzzer, Voice, and
Inhibit.
Allows Speech to be
turned ON or OFF.
1. The model and transmitter to which the
altitude sensor was connected are turned on.
2. Tap to the [Preset] of "Reference" item.
"Vibrator" type
If the following types are selected, the transmitter
will vibrate during the warning.
Type 1
Type 2
Type 3
*An altitude sensor or GPS sensor must be installed in the aircraft.
Allows Melody to be
turned ON or OFF.
105
Displaying data from the
variometer
climbing or descending at a rapid rate.
*It cannot be used in FASST mode and S-FHSS mode.
FASSTest12CH mode.
functions.
Sets the variometer
on which the alarm
operates.
1. Tap Alarm and choose from Buzzer, Voice,
and Inhibit.
2. Choose "Inhibit" for Vibrator if not using the
vibrator alarm. If using vibrator, choose one
of the three types.
3. Tap to the Limit [m/s] item.
buttons.
Initial value: +1m
Adjustment range-50 m/s~+50 m/s
≧
to the initial value.
5. To terminate the input and return to the
original state, push the HOME/EXIT button.
Variometer
● If this is set to Mode1-4,
a rise and dive are told
by a different melody.
Mode 1 : Little rise/dive
→ Melody changes
: sensitively
Mode 4 : Big rise/dive
→ Melody changes
: insensible
