FUTABA T16IZ SUPER Full Manual page 118

Telemetry : Futaba ESC MC-980H/A, MC-9130H/A, MC-9200H/A
◆ Register the ESC with transmitter.
Registration to transmitter
Connect SBM-2 to the S.I / F port on
the back of transmitter.
◆ The registered ESC will be displayed as "Futaba ESC".
◆ The registered Hobbywing ESC is displayed as "Hobbywing ESC".
*Futaba ESC must be installed in the aircraft.
◆ Linkage menu → Sensor → 3/3
● Call page 3 of [Sensor].
Complete registration and remove
SBM-2 from the transmitter.
*Please note that the proper default slot for this accessory is number 8 (8-15).
This sensor uses eight slots. Being made to a start slot are 8, 16, and 24.
118
Connect the SBM-2 to the
transmitter as shown, then
tap Register.
Registration is complete when
this screen appears
For details on Hobbywing ESC telemetry
support, refer to the Hobbywing website.
