S.BUS/S.BUS2 servos or a telemetry sensor can be connected directly to the T16IZ SUPER. Channel
setting and other data can be entered for the S.BUS/S.BUS2 servos or sensors.
1. Connect the S.BUS device as shown in the
2. Turn on the transmitter power.
3. Call the setup screen.
Servo: System Menu
Sensor: Linkage Menu
4. Perform setting in accordance with each
screen.
5. This sets the channel and other data for each
S.BUS servo, or telemetry device to be used
with the S.BUS device or receiver.
WARNING
Do not disconnect or turn transmitter power OFF
while S.BUS servo and telemetry sensor data is
being saved.
■ S.BUS servo and sensor save data will be lost,
resulting in malfunction.
41
S.BUS servo
Sensor
