FUTABA T16IZ SUPER Full Manual page 34

LED Indication
Status
No signal reception
Receiving signals
Waiting for link
Unrecoverable error (EEPROM, etc.)
In Dual RX Link Mode
Status
External receiver is receiving error or not
connected. S.BUS signal not received
S.BUS signal reception from external receiver
(also received by external receiver)
In FASSTest12CH Telemetry OFF Mode
Status
Start
LINK LED
Red Solid
Green Solid
Start → 2second
later → Red Blink
（3 second）
Red Green
Alternate blink
MODE LED
Red Solid
Green Solid
LINK LED
Orange Solid
See your transmitter operation manual for complete details on
operating in the dual receiver mode.
R7208SB/R7308SB CH Mode table
Output
Mode A Mode B
connector
CH 1-8 CH 1-7
1 1 1
2 2 2
3 3 3
SB2 / 4 4 4
SB2 / 5 5 5
SB2 / 6 6 6
SB2 / 7 7 7
SB / 8 8 S.BUS
LED
RED 1 RED 2
blink
Default
1
Turn on the receiver. [Transmitter is always OFF]
2
Press and hold the SW for 5 seconds to 10 seconds.
3
When the LED of the receiver changes from blinking
red to blinking orange, SW is released.
4
The LED should now blink red two times in the
patterns described in the chart below.
5
Each press of the SW advances the receiver to the
next mode.
6
When you reach the mode that you wish to operate
in, press and hold the SW for more than 2 seconds.
When LED blinks in orange, it is the completion of a
mode change, SW is released.
7
Cycle the receiver power off and back on again after
changing the Channel mode.
1
Turn on the receiver. [Transmitter is
always OFF]
2
Receiver enters link waiting state
3
The LED will flash for the current CH
output mode.
34
Channel
Mode C Mode D Mode E Mode F
CH 1-6 CH 1-3 CH 9-16 CH 9-15
1 1 9 9
2 2 10 10
3 3 11 11
4 S.BUS2 12 12
5 S.BUS2 13 13
6 S.BUS2 14 14
S.BUS2 S.BUS2 15 15
S.BUS S.BUS 16 S.BUS
RED 3 RED 4 RED 5 GREEN 1 GREEN 2
LINK LED
Red Solid
Start → 2second
later → Red Blink
（3 second）
Current CH mode
Mode G
CH 9-14
9
10
11
12
13
14
S.BUS2
S.BUS
display
