FUTABA T16IZ SUPER Full Manual page 139

AIL → Camber flap
in the aileron mode. When the aileron stick
perform aileron operation simultaneously and
the operation characteristic of the roll axis is
improved.
model menu and call the setup
screen shown below.
● Mixing curve setting
(For a description of the
setting method, see the
description at the back
of this manual.)
Activate the function by
tapping the [INH].
Condition group/single
mode selection (Gr. /Sngl)
The ON/OFF switch of
mixing is chosen.
To set linking, tap to
the [OFF] item
(ON is displayed.)
the switch and tap the screen to call the
selection screen, and then select the switch
and set its ON direction. (Always ON at "--"
setting)
(For a description of the switch selection
method, see the the back of this manual.)
Adjust the mixing rate.
[Corresponding model type]: Airplane/
AIL
AIL
139
FLP 1
(Camber Flap)
AIL1
(Main Aileron)
AIL 3
(Chip Aileron)
Currently selected condition name
(For a description of the mixing curve setting
method, see the description at the back of
this manual.)
Set it to ON and tap the screen.
FLP 2
(Camber Flap)
AIL 2
(Main Aileron)
AIL 4
(Chip Aileron)
Left/right overall
adjustment at Rate A
and Rate B
Adjustment of each
flap servo
