The angle and curve of each operation function can be set. [All model types]
AFR
When D/R is turned ON, the display will
show "D/R----", and the rudder angle (rate)
and EXP can be set when D/R is ON.
1. When the function select button is tapped, a selection screen appears.
2. Select the function you want to set at the selection screen.
Rate
100%
Rate
40%
the setup screen shown below.
● Operation curve setting
(For a description of the setting method, see the
description at the back of this manual.)
Function selection
133
operation rate through the AFR function.
of curves (EXP1, EXP2, and Point) can be
selected. A maximum 17 points curve can be
used for the point curve type. (Initial setting:
9 points) The number of points can also be
increased and decreased and curves from
complex curves to simple curves can be
used.
speed of each function when the function
is operated (including at flight condition
switching) can be adjusted. The function
operates smoothly at a constant speed
corresponding to the set speed.
● Group/single mode switch (Gr./Sngl)
(For more information, see the
description at the back of this manual.)
● Servo speed setting
(For a description of the setting
method, see the description at
the back of this manual.)
Curve select
EXP1, EXP2, Point curve
Curve select
Separately ⇔ Combination
(Left and right
symmetrical
curve.)
Left/right, Up/down, overall
adjustment at Rate A and
Rate B
