Servo Update - FUTABA T16IZ SUPER Full Manual

Servo update
It is a function for updating the program of Futaba
S.BUS2 servo from T16IZ SUPER.
call the setup screen shown below.
menu
- Insert the micro SD card that contains the "FUTABA" folder into the transmitter.
1. Connect the S.BUS/S.BUS2 servo to the transmitter as
shown above.
2. Turn on the power of the transmitter and select [Servo
update] in the system menu.
3. Tap [Update] to start the software update for that servo.
Tap the update button.
This function updates the corresponding Futaba S.BUS servos.
4. It is complete when [Update succeeded.] is displayed
on the screen.
65
HV (high voltage)
non-compatible servo
HV (high voltage)
compatible servo
