Press the tab to
open the battery
cover.
Install the battery into the transmitter
This connector connects to
the transmitter.
Remove the
battery cover
Battery cover
LT2F2000B
LiPo Battery
16
Connect the battery
connector
Close the battery cover completely
Be careful not to pinch
the wiring
Click !
Press the tab to
close the battery
cover.
CAUTION
Be sure to lock the battery cover.
Tab
First insert two tabs
Click !
