FUTABA T16IZ SUPER Full Manual page 38

*Servo is not included in this set.
Wood screw
Rubber
grommet
Brass eyelet
Servo mount
(Airplane/Glider)
To prevent the servo lead cable from being
little slack in the cable and fasten it at suitable
points. Periodically check the cable during daily
maintenance.
Margin in the lead wire.
make a rectangular hole that is a little larger than
Attached screw
Switch cover
Switch
2.3-2.6mm nut
washer
Rubber
grommet
Brass eyelet
Servo mount
2.3-2.6mm screw
(Helicopter)
Fasten about 5-10cm
from the servo outlet so
that the lead wire is neat
and secure.
Less than 5 mm of
mounting plate
WARNING
Connecting connectors
Be sure to insert the connector until it
stops at the deepest point.
How to protect the receiver from vibration and
water
Wrap the receiver with something
soft such as foam rubber to avoid
vibration. If there is a chance of
getting wet, put the receiver in a
waterproof bag or balloon.
Receiver's antenna
Never cut the receiver's antenna. Do
not bind the receiver's antenna with
the cables for servos.
Locate the receiver's antenna as far as
possible from metals or carbon fiber
components such as frames, cables,
etc.
crash.
Servo throw
Adjust your system so that pushrods
will not bind or sag when operating
the servos to the full extent.
servo could be damaged due to force on the gear train
Mounting servos
Use a vibration-proof rubber (such as
rubber grommet) under a servo when
mounting the servo on a servo mount.
And be sure that the servo cases do
not touch directly to the metal parts
such as servo mount.
38
