operated.
Receiver : A Receiver : B
Communicate with two receivers
output and S.BUS2 input/output.
Connection example
Even if there is a problem with
the B receiver, communication
will be performed with the A
receiver.
Even if there is a problem with
the A receiver, communication
will be performed with the B
receiver.
1
Turn on the receiver. [Transmitter is always OFF]
2
Press and hold the SW for 5 seconds or more.
Blinking switches every 5 seconds as follows.
RED ⇒ ORANGE ⇒ GREEN ⇒ ORANGE slow blink
3
Blinks GREEN once
Dual RX Link
mode : OFF
Press SW once
more to return to
flashing green once
4
Blinks GREEN twice
Dual RX Link
mode : ON
5
6
7
After restarting, the
MODE LED lights up.
External receiver is receiving error or not connected.
S.BUS signal not received
S.BUS signal reception from external receiver
(also received by external receiver)
35
If it is passed,
turn off the
Release the
power and
switch here
restart
Press switch
Press and hold the SW
Blinks ORANGE
Release SW
Solid ORANGE
Turn off the receiver power
Status MODE LED
Green Solid
Red Solid
