FUTABA T16IZ SUPER Full Manual page 29

RUD AIL
ELE THR
MODE1
J2 stick
Spring → Hard
Spring → Soft
J2 stick
Ratchet → +
Ratchet → Free
● System menu ⇒ H/W setting
Select stick mode
WARNING
● The changed stick mode will be
reflected from the newly created
model data.
● Change stick mode before entering
model data.
RUD AIL
THR ELE
MODE2
Default
J2 stick
Spring → Free
Spring → ACT
EX: MODE2 → MODE1
AIL RUD AIL
ELE THR
MODE3
J3 stick
Spring → Free
Spring → ACT
Back side
Calibrate after
changing stick mode
● Before the flight, make sure that the
operation of the stick matches the
model operation.
29
RUD
THR ELE
MODE4
J3 stick
Spring → Hard
Spring → Soft
J3 stick
Ratchet → +
Ratchet → Free
J3 J2
