Telemetry : GPS [Distance]
The Distance screen displays and sets altitude data
be read by the transmitter. When the aircraft flies
vibration alerts the pilot.
the setup screen shown below.
Linkage menu
Max. and min. values
s i n c e t h e p o w e r
was turned ON will
display.
↑ An upward arrow
indicates the alarm
will sound when the
d i s t a n c e r e a c h e s
above your set value.
↓ A downward arrow
indicates the alarm
will sound when the
d i s t a n c e r e a c h e s
below your set value.
Alarm is chosen from
Buzzer, Voice, and
Inhibit.
Allows Speech to be
turned ON or OFF.
"Vibrator" type
If the following types are selected, the transmitter
will vibrate during the warning.
Type 1
Type 2
Type 3
*A GPS sensor must be installed in the aircraft.
Tap to the [Preset] of "Reference"
item. Sets the current aircraft position
as the starting point.
110
Displaying data from the Distance Screen
instruction manual.
*It cannot be used in FASST mode and S-FHSS mode.
FASSTest12CH mode.
functions.
Altitude calculated as either straight line distance
(slant) or surface distance on a map can also be
selected.
Surface
Select <Slant> <Surface> to "Distance mode", tap the
screen.
Distance
Sets the distance
on which the alarm
operates.
Altitude
