FUTABA T16IZ SUPER Full Manual page 189

Gyro [Helicopter]
model menu and call
the setup screen.
The operation mode
( A V C S / N O R ) a n d
sensitivity of the 3
a x e s G y r o / G y r o 2 /
Gyro3 can be set.
Use this when you want
to adjust sensitivity via
VR, etc., and not on-
screen data entry. Tap "--
", select "VR", etc., and
then tap the value to
adjust. (Won't operate
when value is "0".)
displayed.)
other conditions, select the group mode.
When you want to set the selected condition
only, select the single mode (initial setting).
condition. (Rate 1/Rate 2/Rate 3)
Gyro（RUD) Gyro2（AIL)
setting setting
When using Rate2/Rate3, make it
INH → ON or OFF.
189
Note: [Gyro] [Gyro2] [Gyro3] Default function
[Gyro]: CH6(FASSTest12CH) CH5(Other system type)
[Gyro2] :
[Gyro3] :
Always set to [--] both (control) and (trim) for
the [Gyro] function at the Function menu in
the Linkage menu.
Gyro3（ELE)
setting
Tapping these will
pull up the detailed
selection screen for
each.
Rate1 Gyro type and
gain
Rate2 Gyro type and
gain
Rate3 Gyro type and
gain
Condition group/
single mode selection
(Gr. /Sngl)
The ON/OFF switch
of gyro is chosen.
3 rate (gyro gain)
adjustment
