How to update T16IZ
Your  Futaba  T16IZ  transmitter  programming  can  be  updated  easily
online.    When  functions  are  added  or  improved,  the  update  file
can be downloaded from our website. Copy the update files to the
microSD  card  and  then  use  the  following  procedure  to  update  the
program. Check our web site for the FAQ regarding updating for more
information.
Note: If the battery fully discharges during
program updating, updating will fail. When
the remaining battery capacity is 50% or
less, always recharge the battery before
updating.
Note: The model data in the transmitter can
be used unchanged after updating, but to
be safe, back up the model data before
updating.
1. Download the zip file of the update data
from our website.
Futaba WEB
16IZ Update Zip file
Download
3. The "FUTABA" folder will be created on your
computer.
4. Copy the "FUTABA" folder into your microSD
card.
Copy the "FUTABA"
folder into your SD card.
Note: If the microSD card has already had
"another FUTABA" folder before you make a
copy, the "FUTABA" folder is OVERWRITTEN.
5. Insert the microSD card with "FUTABA" folder
that contained the update software into the
SD card slot on your T16IZ radio transmitter.
6. Turn on the transmitter power while pressing
down the "HOME/EXIT" button. The update
screen appears on the LCD display of your
T16IZ and the software update is started.
2
1
Press the HOME/EXIT switch and turn on
Updating
Installed  microSD  card
of the update file

Advertisement

loading
Need help?

Need help?

Do you have a question about the T16IZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUTABA T16IZ

Summary of Contents for FUTABA T16IZ

  • Page 1 How to update T16IZ  Your  Futaba  T16IZ  transmitter  programming  can  be  updated  easily  online.    When  functions  are  added  or  improved,  the  update  file  can be downloaded from our website. Copy the update files to the  microSD  card  and  then  use  the  following  procedure  to  update  the  program. Check our web site for the FAQ regarding updating for more  information. 5. Insert the microSD card with "FUTABA" folder...
  • Page 2 1. Detach the battery from the transmitter. Complete 2. Insert the microSD card that contained 3. Attach the battery to the transmitter 8. Turn off the power switch of your T16IZ and while pressing down the "HOME/EXIT" remove the microSD card from the card slot. button.
  • Page 3 This software updates or alters the functions and features noted below. The instructions and information that follow are meant as a supplement to the original instruction manual that accompanied the T16IZ transmitter. Please refer to the original instruction manual where applicable, but replace the steps indicated below with these instructions.
  • Page 4 The current rate numbers C1 to C5 are displayed by operating the channel of the transmitter. Like the flight condition function of the transmitter, you can set up to 5 different data for the attitude holding force rate of the aircraft in AVCS mode by operating the switch from the transmitter, and switch between them.
  • Page 5 This software updates or alters the functions and features noted below. The instructions and information that follow are meant as a supplement to the original instruction manual that accompanied the T16IZ transmitter. Please refer to the original instruction manual where applicable, but replace the steps indicated below with these instructions.

  • Page 6: Alarm Setting

    ◆ MC-9130H / A telemetry connection example  To CH3 Throttle To free port To S.BUS2 SBM-2 To drive battery  ◆ ESC telemetry display screen Tap to move to the  The ESC status is displayed. Alarm setting is also possible. temperature setting page.  Tap to move to the  current setting page. Tap to move to the  voltage setting page. Tap to move to the  capacity setting page. Tap to move to the  rotation setting page. Display max / min value Press and hold to reset.  Display max / min value Shows the output level from the ESC  ◆ Alarm setting Press and hold to reset.  to the motor, not the position of the ...
  • Page 7 Decreasing the value weakens the holding power and makes the operation feeling closer to the Normal mode. 1. Add GYA553 Airplane Gyro setting function. (Refer the T16IZ GYA553 Setting Manual) 2. Compatible with SCORPION ESC telemetry Added support for SCORPION POWER SYSTEM ESC some models.
