FUTABA T16IZ SUPER Full Manual page 195

Before making Wireless tunings, it is necessary to download the setting data from the gyro to the T16IZ SUPER via a wired
connection.
T16IZ SUPER
1
1. Select "Gyro setting" on the last page of
Helicopter Model Menu
Once the gyro data is stored in the T16IZ SUPER, if it is the same gyro, there is no need to make a wired connection from the
second time on. If you want to use another gyro, you need to reconnect the cable and download the data.
To configure the Wireless tunings, set two consecutive
free channels to use for Wireless tunings in SBUS Basic
4/4.
2 consecutive free channels
1
1. Select "Gyro setting" on the last page of
Helicopter Model Menu
3
3. Select "Wireless Tuning"
SETTING
B. Wireless tunings
First, wired connection
CGY755/CGY760R
S.I/F
CGY Connection Cable (included with gyro)
Next, Wireless tunings
Check that the gyro to be
set matches the EQ ID.
195
● Connect the receiver battery (3.5 to 8.4 V) to
one of the "AIL" to "S.B2" connectors other
than "RPM" and "P.BOX".
(Do not connect to "RPM" and "P.BOX".)
P.BOX
2
2. Select "Start"
This will download the gyro data to the T16IZ SUPER.
Linkage menu → Function
Example using 13CH and 14CH
Set Control and Trim to NULL ( -- ).
2
2. Select "Start"
4
4. Items that can be set wirelessly are displayed
When "GY Settings Transfer" is
selected, the gyro setting data saved
in T16IZ SUPER is written to the gyro.
