FUTABA T16IZ SUPER Full Manual page 152

Trim mix 1/2
As an example Trim mix 1 can be set up for
and a slight amount of up elevator. Trim mix
2
The trim functions can be activated during
mix 1.
When using this
function, Tap [INH].
(ON is displayed.)
The ON/OFF switch of
mixing is chosen.
M a n u a l / A u t o m o d e
selection
Manual: Switches the
f u n c t i o n O N / O F F b y
switch
Auto: Trim mix function
call can be linked to a
stick, etc. A stick switch,
etc. separate from the
function ON/OFF switch
is set.
Condition delay setting
[Corresponding model type]: Glider, general
menu and call the setup screen
shown below.
Condition delay cut
switch
The offset rate of ailerons, flaps and elevators can be adjusted.
Tap to the corresponding setting item. Adjust the rate.
1. Move to the [INH] item
[ON].
2. Select the ON/OFF switch.
3. Select the [Manual] or [Auto] mode.
In the [Auto] mode, also select an auto SW. This
switch can be linked to a stick, etc.
<Speed>
In: The operation speed at switch ON can be set.
Out: The return speed at switch OFF can be set.
<Fine Tuning>
The offset rate can be varied in the Fine Tuning
numeric range set at screen by VR, etc. selection.
<Condition Delay>
can be set for each condition. Condition delay
operation can be interrupted and each rudder
quickly returned to its original position by selecting a
cut switch.
*The display screen is an example. The actual
screen depends on the Model Type.
When a fine tuning VR
is set, the trim rates
of ailerons, flaps and
elevators can be adjusted.
152
Example
.
Set the trim mix function to
To next page
In speed
Out speed
（First） 0 〜 27 （ Slowly） （First） 0 〜 27 （ Slowly）
The value inside the
parentheses shows the
current rudder position.
