FUTABA T16IZ SUPER Full Manual page 12

FASSTest system
The T16IZ SUPER transmitter has adopted the bidirectional communication system "FASSTest". Data from the receiver can be
Color touch screen LCD
and outdoor visibility.
S.BUS2 system
Model types
Functions and mixing functions necessary for each model type are set in advance at the factory.
Lithium-ion polymer battery
microSD card (Secure Digital memory card) (Not included)
Edit button
Vibration function
Selects a function that alerts the operator to various alarms by vibrating the transmitter in addition to sounding a buzzer.
Speech function
commercially available earphones.
• T16IZ SUPER Transmitter
• R7208SB or R7308SB Receiver
• LT2F2000B LiPo Battery
(2-stick, 18-channel, FASSTest-2.4 GHz system)
Transmitting frequency: 2.4 GHz band
System: FASSTest 18CH/FASSTest 12CH/S-FHSS/T-FHSS/
FASST MULT(Europe is not supported)/FASST 7CH(Europe is not supported) switchable
Power supply: 7.4 V LT2F2000B LiPo battery
Frequency band: 2.4 GHz
RF power output : 100 mW EIRP
(FASSTest-2.4 GHz system, Dual Antenna Diversity, S.BUS/S.BUS2 system)
Dual antenna diversity ( R7308SB Sleeve antenna)
Power requirement: 3.7 V-7.4 V battery or regulated output from ESC, etc. (*1)
Battery F/S Voltage: It sets up with a transmitter
Extra Voltage port: 0-70 V DC
Size: 0.98 x 1.53 x 0.56 in. (24.9 x 38.8 x 14.3 mm)
Weight: R7208SB 0.35 oz. (9.9 g) / R7308SB 0.39 oz. (11.0 g)
Frequency band: 2.4 GHz
Note: This set does not include a charger. Use a commercially available USB charger AC
adapter (USB-A type 5 V-2 A) or the Futaba optional USB AC adapter.
Note: The battery in the T16IZ SUPER transmitter does not arrive already attached to the
battery connector. Please connect the battery connector before use.
• USB Cable
• Short Manual
• Hex Key
• Tx Strap
12
*The contents may vary on the type of set.
