Telemetry: Receiver [Ext. battery]
is necessary to connect external voltage connector
measure the voltage of
to call the setup screen shown below.
Linkage menu
Max. and min. values
since the power
was turned ON will
display.
↓ The "down" arrow
will indicate that an
alarm will sound when
the voltage drops to
below the setting.
Alarm is chosen from
Buzzer, Voice, and
Inhibit.
Allows Speech to be
turned ON or OFF.
1. Tap Alarm and choose from Buzzer, Voice,
and Inhibit.
2. Choose "Inhibit" for Vibrator if not using the
vibrator alarm. If using vibrator, choose one
of the three types.
3. Tap to the Limit [4.0 V] item.
buttons.
Initial value: 4.0 V
Adjustment range: 0.0 V~100.0 V
to the initial value.
5. To terminate the input and return to the
original state, push the HOME/EXIT button.
*CA-RVIN-700 must be installed in the aircraft.
voltage set by you is exceeded.
*It cannot be used in FASST mode and S-FHSS mode.
FASSTest12CH mode.
.
functions.
If the following types are selected, the transmitter
will vibrate during the warning.
Type 1
Type 2
Type 3
101
Displaying data from the EXT
battery voltage port
Ext. battery
voltage
Sets the voltage on
which the alarm
operates.
"Vibrator" type
