Opening the Printer

You need to open the printer when you load media or perform most other
maintenance procedures.
To open the printer
1. Facing the front of the printer, grasp the right side of the front cover and
2. Grasp the bottom center of the right side cover and pull it upward. The

Closing the Printer

To close the printer after loading media or performing printer maintenance
1. Grasp the topmost part of the side cover and gently rotate it down until it
2. Swing the front cover to the closed position until the magnetic latches

Using the Front Control Panel

The front control panel of the 4100
printer, illustrated at right, contains
three buttons and three indicator
lights that you use in the normal
operation of the printer. The table on
the next page describes the control
panel components.
3-4
pull it toward you to release the cover from its magnetic latches.
hinged right cover should come to rest on the top of the printer.
rests against the printer.
securely hold the cover.
Helvitica condensed 9 pt italic
C o d e 3 9
PAUSE
FEED
STOP/
CANCEL
DARKER
1 8 p t
PAPER/
RIBBON
POWER
TRANSFER ON
4100-01b
