Intermec EasyCoder 4100 User Manual page 167

Helvitica condensed 9 pt italic
C o d e 3 9
Command
d3,3/4;
Fr Goth
h3;
w7;
L11;
o300,140;
f3;
l130;
w8;
L12;
o25,270;
l275;
w8;
H13;
o60,560;
f1;
c0;
d0,20;
h3;
w2;
L14;
o140,270;
f3;
l310;
w8;
H15;
o360,120;
c22;
d3,DUPLEX ANGLE
CONNECTOR;
h3;
w1;
H16;
1 8 p t
Description
Defines constant data for field 10.
Sets the height to three times the original size.
Sets the width to seven times the original size.
Defines field 11 as a line field.
Sets the origin for field 11 at (300,140).
Rotates field 11 270 degrees counterclockwise around the origin.
Sets the length of the line in field 11 to 130 dots.
Sets the width to 8 dots.
Defines field 12 as a line field.
Sets the origin of field 12 at (25,270).
Sets the length of the line in field 12 to 275 dots.
Sets the width of field 12 to 8 dots.
Defines field 13 as a human-readable field.
Sets the origin of field 13 at (60,560).
Rotates field 13 90 degrees around the origin 25.
Determines that field 13 prints in font 0.
Specifies that data for field 13 will be entered during Print mode and that
the data will be a maximum of 20 characters long.
Sets the height of field 13 to three times the actual size.
Sets the width of field 13 to two times the actual size.
Defines field 14 as a line field.
Sets the origin of field 14 at (140,270).
Rotates field 14 270 degrees counterclockwise around the origin.
Sets the length of the line in field 14 to 310 dots.
Sets the width of field 14 to 8 dots.
Defines field 15 as a human-readable field.
Sets the origin of field 15 at (360,120).
Determines that the field prints in font 22.
Defines constant data for field 15.
Sets the height to three times the original size.
Sets the width to original size.
Defines field 16 as a human-readable field.
Designing Labels and Using Commands
6
6-35
