4100 Bar Code Label Printer User's Manual
Situating the Printer
The printer has these physical requirements:
• A location within 5 feet (1.5 m) of an electrical source
• A level, sturdy operating area
• Easy access to the power switch and the rear panel
• Make sure the printer is located away from potential hazards, such as water
Connecting the Printer to the Host
You are now ready to connect your printer to the host computer. The proper
way to connect the printer depends on the way your system is configured. This
section contains procedures for point-to-point and nonswitched modem
installations. References are provided for network installations.
Default (Point-to-Point) Installation
The printer's serial port default settings, shown in the table below, are suitable
for connecting the serial port on the 4100 printer to most host computers. If
these settings are compatible with your system, use the procedure following the
table to connect the printer to the host computer.
Serial port
Baud rate
Data bits
Parity
Stop bits
Protocol
2-4
or other liquids
Helvitica condensed 9 pt italic
C o d e
3 9
Default setting
9600
7
Even
1
Standard
1 8
p t
