Helvitica condensed 9 pt italic
C o d e 3 9
4. Add a 1 in the bit 6 position, and then add a 0 in the bit 7 position so that
each group now has eight digits. (Eight digits complete the byte you
download.)
Fr Goth
5. Reverse the order of each group so that bit 0 is now last and bit 7 is first.
Each eight-digit group is now a binary representation of an ASCII character.
6. Translate each eight-digit group into an ASCII character according to the
chart in the Appendix and the method you'll use to download the data.
7. Make sure the printer is in Advanced mode and not in 86XX Emulation
mode.
8. Download the graphic so that each column is represented by a command
string.
Here is the same diamond shape graphic shown earlier, but this time it is in six
bits per byte format with ASCII characters.
<STX><ESC>C<ETX>
<STX><ESC>P;<ETX>
<STX>G2,diam;x15;y16;<ETX>
<STX>u0,@B@;<ETX>
<STX>u1,@E@;<ETX>
<STX>u2,'H@;<ETX>
<STX>u3,PP@;<ETX>
<STX>u4,H'@;<ETX>
<STX>u5,D@A;<ETX>
<STX>u6,B@B;<ETX>
<STX>u7, G;<ETX>
<STX>u8,~CB;<ETX>
<STX>u9,|CA;<ETX>
<STX>u10,xc@;<ETX>
<STX>u11,pS@;<ETX>
<STX>u12,'K@;<ETX>
<STX>u13,@G@;<ETX>
<STX>u14,@B@;<ETX>
<STX>R<ETX>
1 8 p t
Designing Labels and Using Commands
6
6-21
