4100 Bar Code Label Printer User's Manual

Setting the X Forms Adjust

When you move the X origin forward, the printer moves the top of form away
from the edge before printing the label information. When you move the X
origin backward, the printer moves the top of form closer to the edge before
printing the label information.
To set the X Forms Adjust
1. Power off the printer.
2. Enable Test and Service mode by moving Switch 8 on the bottom bank of
3. Turn on the power to the printer. The printer is now in Test and Service
4. In the top bank of the Test and Service DIP switches, turn on Switches 1, 2,
5. In the bottom bank of the Test and Service DIP switches, turn on or off the
6. Press the [FEED] button.
7. Verify the X Forms Adjust number on the software configuration label
8. Exit Test and Service mode by cycling the printer power and returning the
5-22
DIP switches to the 1 or on position.
mode.
3, and 4.
To move the X origin forward, turn off Switch 5.
To move the X origin backward, turn on Switch 5.
Top Bank
OFF
ON
1 2
Switch settings
for moving the
X origin forward
appropriate DIP switches. See the Dot Increments DIP Switch Settings table
to set the X Forms Adjust forward or backward a given number of
increments.
The printer prints out the software configuration label.
matches the number you set in Step 4.
DIP switches back to their original settings.
Helvitica condensed 9 pt italic
C o d e 3 9
OFF
ON
3 4 5 1
1 8 p t
Top Bank
2 3 4 5
Switch settings
for moving the
X origin backward
4100.29
