4100 Bar Code Label Printer User's Manual
Printer Component
Driver roller and tear-off plate
Media path
Case
Printhead
Cutter

Lubrication

All bearings in the 4100 printer are either permanently lubricated or made of
low friction plastic and do not require maintenance lubrication. The three slip
clutches in the printer are prelubricated and should not require further
lubrication. However, if the printer mechanism creates a squeaking or
humming noise, contact your Intermec representative for assistance.

Cleaning the Printer

The following procedures tell you how to access printer components and clean
them without causing any damage.
Note: Before cleaning any components, turn off and unplug the printer.

Cleaning the Drive Roller

If the drive roller becomes contaminated with grit, label adhesive, or ink, your
print quality may deteriorate. Clean the drive roller whenever these conditions
occur.
Tools Required: Phillips screwdriver, cotton swabs or clean cloth, 70%
isopropyl alcohol.
4-6
Helvitica condensed 9 pt italic
C o d e 3 9
Maintenance Period
Clean whenever contaminated by debris.
Clean whenever contaminated by debris.
Clean as necessary.
Clean every 50,000 linear inches of media
(approximately eight 6,000-inch rolls) for direct
thermal printing. Clean every 250,000 linear
inches (approximately 41 6,000-inch rolls) for
thermal transfer printing.
Clean after every 5,000 to 10,000 labels cut.
Replace after 500,000 cuts per side (total 1
million cuts).
