Printer Component Descriptions (Mechanism Detail)

The following table contains descriptions of the printer components as shown
in the previous illustration.
No. Name
1 Supply roll back stop
2 Supply roll retainer
3 Supply roll hanger
4

Rewind adapter

5 Rewinder clasp
6 Rewinder hub
7 Label adjust guide
8 Head lift lever
9 Label gap sensor adjustment
10 Printhead
11 Printhead support adjust screw
12 Tear off plate
13 Printhead support plate
14 Ribbon rewind hub
15 Ribbon clasp
16 Ribbon supply hub
17 Ribbon supply back stop
1 8 p t
Description
Prevents the roll of unused media from rubbing against the
interior of the printer.
Secures the roll of unused media to the supply roll hanger.
Holds the roll of unused media.
Guides printed media onto the rewinder hub during batch
take-up printing. (Shown in its storage position when not in
use).
Secures printed media or used media backing to the
rewinder hub.
Collects printed media in batch take-up mode or media
bacing in self-strip mode.
Guides media from the supply roll to the drive roller.
Disengages the printhead for loading media or ribbon and
for adjusting printhead alignment.
Adjusts the label gap sensor, which scans the media for label
gaps or edges so the printer can determine where to start a
new label. Adjustable from 0.25" to 2.3".
Prints label formats as they are transmitted from the host
computer. The printhead resolution is 203 dots per inch
(DPI).
Moves the printhead support plate up or down to
accomodate narrow media.
Used for tearing off labels in straight-through printing mode.
Supports the outer end of the printhead when narrow media
is used.
Collects used thermal transfer ribbon.
Secures used thermal transfer ribbon to the ribbon rewind
hub.
Holds the supply of unused thermal transfer ribbon.
Prevents the roll of thermal transfer ribbon from rubbing
against the interior of the printer.
