Helvitica condensed 9 pt italic
C o d e 3 9
Format
<STX>
<ESC>c
Fr Goth
<ETX>
<ESC>P
E4;F4;
H0
o120,50
f0
c2
h2
w1
d0,30
B1
o170,220
c0,1
h50
w1
i0
d0,11
p@
R
Data
<ESC>E4
<CAN>
THIS IS A SAMPLE LABEL
<CR>
SAMPLE
<ETB>
1 8 p t
Mark the beginning of this message line.
Select 8636/46 emulation mode.
Mark the end of this message line.
Enter programming mode.
Erases anything previously stored as format 4 and accesses the
location for format 4.
Define field 0 as a human-readable field.
Set the origin of field 0 at coordinates 120,50.
Do not rotate the field.
Determines that field 0 will print in font 2.
Set the height for field 0 to two times actual size.
Set the height for field 0 to actual size.
Specify that the data for field 0 will be entered in Print mode and
that the data will be a maximum of 30 characters long.
Define field 1 as a bar code field.
Set the origin of field 1 at coordinates 170,220.
Select Code 39, the printer enters a check digit.
Set the height for field 1 to 50 dots.
Set the width for field 1 to actual size.
No human-readable interpretive field will print below the bar code.
Specify that the data for field 1 will be entered in Print mode and
that the data will be a maximum of 11 characters long.
The bar code will not have a prefix.
Exit Programming mode and enter Print mode.
Accesses format 4 from the printer's memory
Clears all host-entered data for the current format and sets the field
pointer to the lowest field.
This is the data for the first field.
Instructs the printer to go to the next data entry field.
This is the data for this field.
Tells the printer to print the label.
Designing Labels and Using Commands
6
6-5
