4100 Bar Code Label Printer User's Manual

Configuration Parameters Upload

Configuration parameters are uploaded in the form of configuration commands that the printer
would receive to set those parameters. The commands are concatenated into one command string
within a message. The following table lists the order in which the commands are transmitted and
the number bytes in each command.
Command
Set message delay
86XX/Advanced mode on power up
Enable/disable cutter
Set end-of-print skip distance
Set darkness adjustment
Set top of form
Select media sensitivity
Set number of image bands
Set maximum label length
Select printer language
Define amount of storage ram
Enable/disable label retract
Set label retract distance
Set print speed
Enable/disable interlabel ribbon save
Select label stock type
Disable ribbon save zones
Set all 10 ribbon save zones
Set intercharacter delay
Set preamble
Set postamble
Disable auto-transmit 1, 2, & 3
A-12
Helvitica condensed 9 pt italic
C o d e 3 9
Syntax
<ESC><SYN> [n]
<SI>C[n]
<SI>c[n]
<SI>D[n]
<SI>d{n}
<SI>F[n]
<SI>g[n,m]
<SI>I[n]
<SI>L[n]
<SI>l[n]
<SI>N[n]
<SI>R[n]
<SI>r[n]
<SI>S[n]
<SI>s[n]
<SI>T[n]
<SI>Z
<SI>Z[n,mx10]
<SYN>[n]
<SOH>[n]
<EOT>[n]
<ESC>k
1 8 p t
Bytes
6
3
3
6
5
6
7
4
6
3
5
3
5
4
3
3
2
110
5
2-3
2-3
2
