4100 Bar Code Label Printer User's Manual

Intermec Cables

Intermec offers a full line of interface cables. These cables are not included with
the printer and must be ordered separately. Contact your Intermec
representative for ordering assistance.
For connecting the 4100 printer to an IBM PC AT or compatible, use this
Intermec cable: Intermec Part No. 048693.
For connecting the 4100 to an IBM PC XT or compatible, use this Intermec
cable: Intermec Part No. 048668.

Cable Schematics

If you are making your own cables, the following diagrams show cable
schematics for some of the more commonly used cables.

RS-232 Null Modem Cable for PC

25-PIN (SOCKET) D-SUB
METAL BACKSHELL
CHASSIS GROUND
TRANSMITTED DATA
RECEIVED DATA
REQUEST TO SEND
CLEAR TO SEND
DATA SET READY
GROUND
DATA TERMINAL READY
CARRIER DETECT
2-18
SHIELD
1
2
3
4
5
6
7
20
8
PC
NOTE: The metal backshell is connected directly
to the shield to achieve electrostatic discharge
(ESD) immunity.
Helvitica condensed 9 pt italic
C o d e 3 9
25-PIN (PLUG) D-SUB
METAL BACKSHELL
CHASSIS GROUND
1
RECEIVED DATA
3
TRANSMITTED DATA
2
CARRIER DETECT
8
DATA TERMINAL READY
20
GROUND
7
DATA SET READY
6
4
CLEAR TO SEND
5
PRINTER
1 8 p t
4100-12
