4100 Bar Code Label Printer User's Manual
Factory Defaults
The following table lists the factory default settings for the 4100 printer. You
can set these parameters by using downloadable printer commands described
in Chapter 7. For information on the printer serial port defaults, which you set
by using the rear panel DIP switches, see Chapter 2.
Configuration
Message delay
Power up mode
Cutter
End-of-print skip distance
Top of form
Media sensitivity
Number of image bands
Maximum label length
Printer character set
Label retract
Label retract distance
Print speed
Label stock type
Interlabel ribbon save
Ribbon-save zones
Intercharacter delay
Preamble character
Postamble character
Auto-transmit 1
Auto-transmit 2
Auto-transmit 3
A-6
Helvitica condensed 9 pt italic
C o d e
3 9
Default Setting
0 milliseconds
Advanced mode
Disabled
100 dots
20 dots
420
3
1000 dots
US ASCII
Enabled
0 dots
3.5 inches per second (ips)
Die cut
Disabled
Disabled
0 milliseconds
Disabled
Disabled
Disabled
Disabled
Disabled
1 8
p t
