Intermec EasyCoder 4100 User Manual page 169

Helvitica condensed 9 pt italic
C o d e 3 9
Command
c21;
Fr Goth
d3,ACE CORP.;
k20;
H23;
o210,670;
c21;
d3,ADDRESS 3010;
k10;
H24;
o210,710;
c21;
d3,FICTION USA;
k10;
B25;
o685,615;
c0,0;
d0,20;
i1;
h100;
p@;
I25;
h2;
w2;
L26;
o590,580;
f3;
l175;
w8;
W27;
o015,000;
w10;
1 8 p t
Description
Determines that field 22 prints in font 21.
Defines constant data for field 22.
Sets the point size to 20.
Defines field 23 as a human-readable field.
Sets the origin of field 23 at (210,670).
Determines that field 23 prints in font 21.
Defines constant data for field 23.
Sets the point size to 10.
Defines field 24 as a human-readable field.
Sets the origin of field 24 at (210,710).
Determines that field 24 prints in font 21.
Defines constant data for field 24.
Sets the point size to 10.
Defines field 25 as a bar code field.
Sets the origin of field 25 at (685,615).
Sets the bar code font to Code 39 with no check digit.
Determines that the data for field 25 is entered during print mode and its
maximum length is 20 characters.
Determines that an interpretation of the bar code prints with start and
stop characters included.
Determines that the bar code height is 100 dots.
Clears all prefixes from the bar code field.
Defines field 25 as an interpretive field.
Sets the height to two times the original size.
Sets the width to two times the original size.
Defines field 26 as a line field.
Sets the origin of field 26 at (590,580).
Rotates field 26 270 degrees counterclockwise around the field origin.
Sets the length of the line in field 26 to 175 dots.
Sets the width of field 26 to 8 dots.
Defines field 27 as a box field.
Sets the origin of field 27 at (015,000).
Sets the width of field 27 to 10 dots.
Designing Labels and Using Commands
6
6-37
