Command Code Summary
R Test and Service Mode, Exit
S Transmit Printhead
Resistance Values*
T Label Taken Sensor Value,
Transmit
U 40 Volt Supply Value,
Transmit*
V Printhead Volt Supply
Value, Transmit*
; Command Terminator
* The 4100 printer ignores this command
1 8 p t
Description
Causes the printer to exit Test and Service mode.
Transmits the average, maximum, and minimum
printhead dot resistance value back to the host.
Each value is a numeric data string separated by a
comma.
Transmits the label taken sensor A/D output back
to the host. The range of the value is 00 to 255.
Transmits the 40 volt supply A/D output back to
the host. The range of the value is 00 to 255.
Transmits the printhead volt supply A/D output
back to the host. The range of the value is 00 to 255.
All commands in Test and Service mode must end
with the command terminator except for the last
command in a message.
.
