4100 Bar Code Label Printer User's Manual

Configuring the Serial Port

The 4100 printer's serial port settings should match those of your host
computer or network controlling device. If you need to change the default
settings, refer to the following tables. Use a small screwdriver or other
suitable tool to move the DIP switches to the desired settings. The switches
should click securely into the 1 (ON) or 0 (OFF) positions. The printer must
then be turned off and on for the new switch settings to take effect.

Serial Port Settings

The following table summarizes your choices for the printer serial port
settings.
Parameter Settings
Baud Rate 110, 300, 600, 1200, 2400, 4800,
9600, 19200
Data Bits 7 or 8
Parity Odd, Even, None
Stop Bits 1 or 2
Protocol Standard, XON/XOFF,
Multi-Drop, Polling Mode D
Device Address A to Z, 0 to 5
Test and Service Enabled or Disabled
Self-Strip Enabled or Disabled
2-8
Helvitica condensed 9 pt italic
C o d e 3 9
Description
The rate, in bits per second, at which the host exchanges
data with the printer.
The number of bits that represent the ASCII characters.
Checks each transmitted character for errors.
Bits that follow each character to synchronize character
transmission.
The type of network used to connect the printer, the host,
and the rest of the data collection system.
Unique address for each device connected with
Multi-Drop protocol.
Provides printer diagnostics to the host and prints test
labels.
Peels the media backing away from labels one at a time
for on-demand printing.
