Printer Component Descriptions (Front Interior)

The following table contains descriptions of the printer components as shown in
the previous illustration.
No. Name
1 Drive roller
2 Rewind assist roller
3

Transfer on switch

4 Darkness control adjustment
5 Quick remove hinge
1 8 p t
Description
Advances media through the printer.
Guides media to the rewinder hub during batch take-up and

self-strip printing.

Toggles between direct thermal printing (OFF) and thermal
transfer printing (ON). Direct thermal printing is the factory
default.
Adjusts a new printhead to produce the same level of
darkness as the previous printhead. Does not adjust the
darkness quality of individual print jobs.
Allows the front cover to be easily removed or installed.
