BCS Line User Manual page 98

87
Parameter
Zoom
Focus
Iris
PTZ movement
Expanded PTZ Control Panel
On the basic PTZ control panel, click
options. See Figure 4-95.
● The functions with buttons in gray are not supported by the system.
● Right-click once to return to the interface of PTZ basic control panel.
Icon Function
Preset
Tour
Pattern
Copyright © NSS Sp. z o.o.
Description
: Zoom out.
: Zoom in.
: Focus far.
: Focus near.
: Image darker.
: Image brighter.
Supports eight directions.
Fast positioning button.
● Positioning: Click
click anywhere on the live view screen, the PTZ will turn to this
point and move it to the middle of the screen.
● Zooming: On the fast positioning screen, drag to draw a square on
the view. The square supports zooming.
● Dragging upward is to zoom out, and dragging downward is to
zoom in.
● The smaller the square, the larger the zoom effect.
This function is for some series products only and can only be
controlled through mouse operations.
Click , you can control the four directions (left, right, up, and down)
PTZ movement through mouse operation.
Click to open the expanded PTZ control panel.
to open the expanded PTZ control panel to find more
Figure 4-95
87
to enter the fast positioning screen, and then
Icon Function
Pan
Flip
Reset
User's Manual
