Record Control - BCS Line User Manual

User's Manual
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
enable the channel record function when corresponding alarm occurs. For
example, when the alarm type is MD, select Main Menu > ALARM > Video
Detection > Motion Detection, select the record channel and enable record
function. See Figure 4-42.
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
refer to "1.8.5 Video Detection", "1.8.3 Alarm Input", "1.7.1.3 IVS" and "1.9 POS"
for detailed information.
Step 5 Refer to "4.1.4.6.1 Recording Schedule" to set snapshot period.
Step 6 Click Apply button to save snapshot plan.
Enable auto snapshot function so that the snapshot plan can become activated. Refer
to "1.1.4.6.3 Record Control" for detailed information.

1.1.4.6.3 Record Control

After set schedule record or schedule snapshot, you need to enable auto record and snapshot
function so that system can automatically record or snapshot.
● Auto: System automatically records at the type and record period you set in Schedule
interface.
● Manual: System records general files for all day.
Figure 4-41
Figure 4-42
