BCS Line User Manual page 105

User's Manual
No. Function
3 Time Bar
Play Status
4
Record type
5 Search type
6 Calendar
Description
Display the type and time period of the current recorded
video.
● In the 4-channel layout, there are four time bars are
displayed; in the other view layouts, only one time bar
is displayed.
● Click on the colored area to start playback from a
certain time.
● In the situation when you are configuring the settings,
rotate the wheel button on the time bar, the time bar
is zooming in from 0. In the situation when playback is
ongoing, rotate the wheel button on the time bar, the
time bar is zooming from the time point where the
playback is located.
● Time bar colors: Green indicates general type; Red
indicates external alarm; Yellow indicates motion
detection; Blue indicates intelligent events; Purple
indicates POS events.
● Click and hold the time bar, and the mouse pointer
shall change to a hand icon, and then you can drag to
view the playback of the target time.
● You can drag the vertical orange line on the time bar
to rapidly view the playback in iframe format.
● When playing back video in one channel mode, you
can move mouse pointer to time bar for 0.1 seconds
to display thumbnail pictures for the video of selected.
Four pictures before and four pictures after the
selected time, and the thumbnail picture of the
selected time will be displayed.
● For some models, when you are clicking on the blank
area in the time bar, the system automatically jumps
to the next time point where there is a recorded video
located.
Includes two playback status: Play and Stop.
Select the check box to define the recording type to
search for.
Select the content to play back: Record, Picture,
Subperiod. For details about the selecting search type,
refer to "1.6.2.2 Search Type" for detailed information.
Click the date that you want to search, the time bar
displays the corresponding record.
The dates with record or snapshot have a small solid
circle under the date.
